EMCOD 2-in-1 LED Driver Dimmer 60W 12VDC Class 2

Product Overview

The EMCOD EDD60-12DC-CCT is a compact 2‑in‑1 LED driver and dimmer for tunable‑white (CCT) LED applications. It provides a 12V DC constant‑voltage PWM output with a 60W maximum load and integrated CCT control on the CCT model.

The unit is listed as Class 2 and includes short‑circuit, overload, and over‑temperature protections. Its small footprint can fit in constrained spaces; confirm fit for your installation.

Key Features

• SKU: EDD60-12DC-CCT — 2‑in‑1 LED driver with integrated dimmer and CCT control
• Output: 12V DC constant‑voltage PWM
• Maximum load: 60W
• Class 2 output
• Protections: short circuit, overload, over‑temperature
• Compact dimensions: H 4.1 in × W 1.73 in × D 1.6 in

What this unit does

The EDD60-12DC-CCT combines a 12V DC constant‑voltage LED driver with an integrated dimmer and a CCT control interface (on the CCT variant) intended for tunable‑white LED fixtures.

• Integrated driver and dimmer design to reduce separate component needs
• CCT control available on the CCT model for tunable‑white fixtures

Output and power performance

This model supplies up to 60W at 12V DC via a constant‑voltage PWM output. The product listing references a dimming range on the family CCT specification.

• Maximum load: 60W
• Output type: 12V DC constant‑voltage PWM
• Dimming range: referenced as 0.3% to 100% on the CCT family specification

Recommended applications

The listing describes use with tunable‑white LED lighting and common low‑voltage LED applications. Confirm compatibility with your specific fixtures and control method.

• Tunable‑white LED fixtures (CCT model)
• LED strip lighting
• Cabinet and under‑cabinet lighting
• Low‑voltage architectural accent lighting

Dimensions and installation considerations

The compact footprint can help where space is limited. Verify physical fit and wiring access at the planned mounting location prior to installation.

• Dimensions: H = 4.1 in, W = 1.73 in, D = 1.6 in
• Input voltage: 120VAC (as listed) — ensure installation complies with local electrical codes

Protections and ratings

The product listing indicates Class 2 output and built‑in protections to help protect the driver and connected LEDs.

• Class 2 output
• Protections: short circuit, overload, over‑temperature
• Family documentation lists active power factor correction (PFC) and a 5‑year warranty

Before You Order

Confirm you select the CCT variant (EDD60-12DC-CCT) if you require CCT control and that the 12V DC constant‑voltage output matches your fixtures.

• Verify fixture input requirements match 12V DC constant‑voltage output.
• Ensure total connected LED wattage does not exceed 60W.
• Check the unit's physical dimensions against available mounting space.
