EMCOD EGP100P General Purpose Multi-Circuit Transformer 100W 12V/24AC Class 1

Product Overview

The EMCOD EGP100P is a general-purpose hard-wired multi-circuit transformer for low-voltage loads. It provides up to 100W output with selectable 12V/24VAC output by model family and includes standard protection and voltage-boost features for long runs.

Designed for lighting and other low-voltage applications, the EGP100P ships in a black powder-coated indoor/outdoor enclosure and carries a Class 1 designation. SKU: EGP100P.

Key Features

• 100W maximum load for low-voltage circuits
• 12V/24 VAC output (by model family)
• Dimmable magnetic hard-wire power supply
• Primary manually reset circuit breaker included
• Boost tap to compensate voltage drop on long runs
• Black powder-coated indoor/outdoor enclosure
• Class 1 designation

What this transformer does

The EGP100P is a general-purpose multi-circuit transformer intended to power low-voltage loads such as lighting circuits. It is a hard-wired, magnetic transformer designed to be used where a Class 1 low-voltage supply is required.

• Supports low-voltage lighting and general-purpose low-voltage loads
• Single SKU: EGP100P

Output and load performance

This unit supplies up to 100 watts of output power and provides 12V/24VAC output as specified for the model family. Output limitations and circuit-level restrictions are provided by the manufacturer.

• Maximum load: 100W
• Output: 12V/24 VAC (by model family)

Protections and control features

The EGP100P includes a primary manually reset circuit breaker for protection. It is a dimmable magnetic power supply and includes a boost tap to help compensate for voltage drop on long cable runs.

• Primary manually reset circuit breaker (standard)
• Dimmable magnetic design
• Boost tap for voltage-drop compensation

Dimensions and enclosure

The transformer ships in a black powder-coated indoor/outdoor enclosure and has compact dimensions suitable for many installation locations.

• Case finish: black powder-coated (indoor/outdoor)
• Dimensions: H = 7.5, W = 3.09, D = 2.88 (units as provided by manufacturer)

Typical applications

The EGP100P is intended for a range of low-voltage applications where a multi-circuit transformer is required. Typical uses include architectural and commercial lighting and other general-purpose low-voltage installations.

• Architectural lighting
• Commercial lighting
• General-purpose low-voltage loads
• Multi-circuit transformer installations

Before You Order

Confirm the exact model number and that 12V/24VAC and the 100W maximum load meet your project requirements before ordering.

• Verify SKU: EGP100P
• Confirm required output voltage (12V vs 24VAC) for your fixtures
• Confirm total connected load does not exceed 100W
