EMCOD EDR100-12DC Universal 5-in-1 Dimmable LED Driver 100W 12VDC

Product Overview

The EMCOD EDR100-12DC is a 100W constant-voltage LED driver that provides a 12V DC output for low-voltage LED strip lighting and other 12V LED loads.

This SKU supports multiple dimming methods listed for the EDR product family and is supplied in a compact plastic enclosure rated suitable for dry and damp locations.

Key Features

• 100W maximum load with 12V DC constant-voltage output
• Universal input on verified EDR models: 100–277V AC, 50/60Hz (noted for EDR family)
• 5-in-1 dimming methods listed for the EDR family: triac forward/reverse phase, 0/1–10V, resistor, and PWM
• Plastic housing suitable for dry and damp locations
• SKU: EDR100-12DC — UPC: 810064711800
• Class 2: NO for this SKU (listed as not Class 2)

What this driver does

The EDR100-12DC is a constant-voltage LED driver that delivers 12V DC and is rated for a maximum load of 100W. It is intended for low-voltage LED strip lighting and other 12V LED applications where a dimmable, compact power source is required.

• Output: 12V DC
• Maximum load: 100W
• Common uses: low-voltage LED strip lighting and dimmable 12V LED systems

Dimming and controls

Dimming methods listed for the EDR product family include several control options. Confirm the dimming method you plan to use is supported for this SKU and matches your control hardware.

• Listed dimming methods for the EDR family: triac forward/reverse phase, 0/1–10V, resistor dimming, and PWM
• Verify compatibility of your dimmer or control system with the selected dimming method

Electrical input & output

This SKU provides a 12V DC output with a 100W maximum load. The EDR family is noted to include models with universal 100–277V input; that input range is indicated for verified EDR models.

• Output: 12V DC, 100W max
• Input: 100–277V AC, 50/60Hz (noted for verified EDR models)
• Class 2: NO for this specific SKU

Dimensions and enclosure

The driver is supplied in a compact plastic enclosure listed as suitable for dry and damp locations. Confirm mechanical fit at the installation site.

• Dimensions: Height = 4.02 in, Width = 2.10 in, Depth = 3.54 in
• Housing: Plastic; listed as suitable for dry and damp locations

Certifications and Class rating

This SKU is listed as Class 2: NO. The EDR family references compliance such as UL 8750 and UL 1310 for supported Class 2 variants; those compliance notes apply to supported EDR models and not necessarily to this specific SKU.

• This SKU: Class 2 = NO
• Referenced compliance (for supported EDR Class 2 models): UL 8750 and UL 1310

Before You Order

Confirm the model number (EDR100-12DC) and that a non-Class 2, 12V DC, 100W driver meets your project's electrical and code requirements.

• Verify dimmer/control compatibility with the dimming methods listed for the EDR family.
• Confirm mechanical fit using the listed dimensions.
• If Class 2 output or specific certifications are required, obtain official manufacturer documentation for this exact SKU.
