Diode LED 24V 90W Commercial Grade Driver - Class 2 (DI-CV-MW24V90W-277)

Product Overview

The Diode LED DI-CV-MW24V90W-277 is a commercial-grade 90 W constant-voltage LED driver that provides a regulated 24 VDC Class 2 output for low-voltage LED tape and fixtures.

The driver accepts 120–277 VAC input for connection to common line-voltage circuits and provides a constant 24 VDC output for compatible LED loads.

Key Features

• 120–277 VAC input
• Regulated 24 VDC constant-voltage output
• 90 W maximum output power
• Class 2 output

What this driver does

The DI-CV-MW24V90W-277 supplies regulated low-voltage power to LED tape and fixtures. It operates as a constant-voltage driver, providing a 24 VDC output for devices designed for constant-voltage input.

• For use with 24 VDC LED tape, modules, and fixtures designed for constant-voltage input.
• Class 2 output is indicated for simplified low-voltage wiring under applicable codes.

Input and output electrical specifications

Verify compatibility of mains and LED load with the driver's rated input and output before installation.

• Input voltage: 120–277 VAC
• Output voltage: 24 VDC (constant-voltage)
• Maximum output power: 90 W
• Class rating: Class 2

Typical applications

The driver is suitable for powering low-voltage LED systems that require a regulated 24 VDC source.

• Low-voltage LED tape
• 24 VDC LED modules and fixtures
• Retrofit and new-construction low-voltage lighting where a 24 VDC constant-voltage supply is specified

Installation and selection notes

Size the driver so the total connected LED load does not exceed 90 W at 24 VDC. Confirm the mains supply is within the 120–277 VAC input range and follow applicable electrical codes for Class 2 circuits.

• Confirm total connected LED wattage does not exceed 90 W at 24 VDC.
• Verify mains supply is 120–277 VAC before installation.
• Follow local electrical codes for wiring Class 2 outputs.

Before You Order

Verify the LED load is rated for 24 VDC and that the combined load does not exceed 90 W.

• Confirm total connected LED wattage ≤ 90 W at 24 VDC.
• Verify mains supply is 120–277 VAC.

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for Diode LED 24V 90W Commercial Grade Driver - Class 2 (DI-CV-MW24V90W-277). For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
