Diode LED
Diode LED NEON BLAZE 24V Linear LED Light, Top Emitting, 1.2W/ft, 3500K, 65.6ft spool (DI-24V-TE-NBL1-35-65)
Diode LED NEON BLAZE 24V Linear LED Light, Top Emitting, 1.2W/ft, 3500K, 65.6ft spool (DI-24V-TE-NBL1-35-65)
Regular price
$2,050.65
Regular price
Sale price
$2,050.65
SKU:DI-24V-TE-NBL1-35-65
Quantity
Couldn't load pickup availability
The Diode LED DI-24V-TE-NBL1-35-65 LED tape light delivers 89 lm/ft at 3500K with 80+ Diffusion: Zero Line Diffusion CRI on a 24 Volt platform. It runs on Diode LED's low-voltage tape format for interior task, accent, and display lighting.
Key Features
- 80+ Diffusion: Zero Line Diffusion CRI renders finishes and merchandise accurately under close light
- Draws 1.22 W/ft, so a run's total load and driver size are easy to size
- Cut points every 2 in terminate cleanly at cabinet lengths
- Single runs up to 65 ft reduce separate feeds on longer installs
Technical Specifications
| Brand | Diode LED |
|---|---|
| Model / SKU | DI-24V-TE-NBL1-35-65 |
| Product Type | LED Tape Light |
| Voltage | 24 Volt |
| Wattage | 1.22 W/ft |
| Lumens | 89 lm/ft |
| Color Temperature | 3500K |
| CRI | 80+ Diffusion: Zero Line Diffusion |
| Cut Interval | 2 in |
| Max Run | 65 ft |
| Dimmable | Yes Field Cuttable: Yes |
| Location Rating | Outdoor / Wet Location / IP65 |
| Certification | UL Listed 2108 |
Applications
Common applications include:
- Under-cabinet and shelf task lighting
- Cove and millwork accent lighting
- Display and retail lighting
Requires a 24 Volt constant-voltage driver sized above the run wattage; keep this run to outdoor / wet location / ip65 locations.
Lumera Electric carries the Diode LED DI-24V-TE-NBL1-35-65 for high-CRI under-cabinet and display lighting.
