Alteck Box 5 in. AFM0019 LED Outdoor Flush Mount, Selectable CCT

Product Overview

The Alteck Box AFM0019 is a 5-inch integrated LED outdoor flush mount providing 830 lumens from a 14 W LED with field-selectable 3000K, 4000K, or 5000K color temperature (3‑CCT).

Built with 430 stainless steel construction, a clear thick-wall acrylic diffuser with a frosted interior, and an ADA-compliant low profile, the fixture is offered in Brushed Stainless or Black finishes and carries an IP44 rating and ETL listing.

Key Features

• Integrated 14 W LED — 830 lumens, 80 CRI
• Field-selectable 3‑CCT: 3000K, 4000K, 5000K
• IP44 wet-location rating
• Triac (forward-phase) dimmable with compatible wall dimmers
• 430 stainless steel construction; clear thick-wall acrylic diffuser with frosted interior
• ADA-compliant low-profile design
• Rated life: 54,000 hours; ETL listed
• Warranties: 3-year finish, 5-year LED

Function and light output

The AFM0019 produces 830 lumens from a 14 W integrated LED with a nominal CRI of 80. The color temperature is field-selectable between 3000K, 4000K, and 5000K. The diffuser is designed to provide even, diffuse illumination suitable for covered exterior ceiling locations.

• Output: 830 lm
• Power: 14 W
• CRI: 80
• Selectable CCT: 3000K / 4000K / 5000K

Recommended applications

Intended for covered exterior ceiling locations where a low-profile flush mount is desired. Typical uses include covered porches, entry ceilings, soffits, and exterior walkway ceilings.

• Covered porch and entry ceilings
• Soffits and overhangs
• Exterior walkway and passage ceilings
• Replacement of older exterior flush-mount fixtures

Electrical and dimming compatibility

Wired for 120V line-voltage operation. The fixture supports triac (forward-phase) dimming with compatible wall dimmers; confirm the dimmer is rated for low-wattage LED loads and suitable for forward-phase control before installation.

• Voltage: 120V
• Dimming: Triac (forward-phase) — requires compatible dimmer
• Confirm dimmer load range against 14 W LED wattage

Mounting, dimensions, and finishes

Installs as a surface/flush ceiling mount to a standard exterior junction box. The fixture has a low profile (5 in wide, 2.5 in high) and is available in Brushed Stainless or Black finishes (SKU-specific).

• Mounting type: Surface / flush ceiling mount
• Width: 5 in
• Height (depth): 2.5 in
• Material: 430 Stainless Steel
• Diffuser: Clear thick-wall acrylic with frosted inside
• Finish options (SKU-specific): Brushed Stainless (AFM0019-3CCT-W-BSS), Black (AFM0019-3CCT-W-BK)

Ratings, life, and warranty

The fixture carries an IP44 rating and is listed by ETL. The LED is rated for 54,000 hours. Manufacturer warranties include a 3-year finish warranty and a 5-year LED warranty.

• Location rating: Wet Location
• IP Rating: IP44
• Rated life: 54,000 hours
• Safety listing: ETL Listed
• Warranty: 3-year finish, 5-year LED

Before You Order

Verify the required SKU and finish, confirm the mounting location meets the fixture’s IP44 wet-location rating, and ensure a 120V junction box is available.

• Verify SKU for finish: AFM0019-3CCT-W-BSS (Brushed Stainless) or AFM0019-3CCT-W-BK (Black)
• Confirm mounting location and junction box compatibility for surface/flush ceiling installation
• If dimming, confirm the selected wall dimmer supports low-wattage LED loads and forward-phase (triac) control

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for Alteck Box 5 in. AFM0019 LED Outdoor Flush Mount, Selectable CCT. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
