Alora Palais LED Vanity Light WV330106

Product Overview

The Alora Palais WV330106VBCR is an integrated LED wall-mounted vanity light with a ribbed glass finish. It produces 720 lumens at 3000K while consuming 9W and carries a damp-location rating.

Suitable for bathroom and powder-room vanity lighting and mirror-flanking installations. The fixture supports ELV dimming and is listed for Title 24 JA8-2022; it is ETL certified and indicated as ADA-compliant in projection.

Key Features

• Integrated LED — 9W nominal, 720 lumens at 3000K
• High color rendering — 90 CRI
• Dimmable — ELV dimming range 100%–10% (dimmer not included)
• Damp-location rated
• ADA-compliant projection
• Title 24 JA8-2022 listed and ETL certified
• Finish: Ribbed glass (model WV330106VBCR)

What it does

The Alora Palais WV330106VBCR is an integrated LED wall-mounted vanity light with ribbed glass that directs illumination downward. It is intended for use as a bathroom or powder-room vanity fixture and for mirror-flanking installations.

• Integrated LED eliminates bulb replacement for the fixture's light source
• Common use: bathroom and powder-room vanity lighting

Light output and color quality

The fixture is specified to produce 720 lumens at a 3000K color temperature with 90 CRI. Delivered lumens (fixture output in installed conditions) are listed as 217 lm.

• Color temperature: 3000K
• Total lumens: 720 lm
• Delivered lumens: 217 lm
• Color rendering index: 90

Dimming and controls

The fixture supports ELV (electronic low-voltage) dimming down to 10% when used with a compatible ELV wall dimmer. A compatible dimmer must be purchased separately.

• Dimming range: 100%–10%
• Dimmer not included — use a compatible ELV dimmer rated for the fixture's 9W load

Mounting, ratings, and compliance

WV330106VBCR is a wall-mounted fixture (all-orientation mounting) with downward illumination. It is ETL certified, rated for damp locations, indicated as ADA-compliant in projection, and listed for Title 24 JA8-2022.

• Mounting: Wall mount, all orientation
• Illumination direction: Down
• Ratings: Damp-location rated; ADA-compliant projection; Title 24 JA8-2022 listed
• Certification: ETL

Technical and physical details

Constructed of steel and glass, the fixture is designed for 120V input and lists an LED life expectancy of 50,000 hours.

• Material: Steel + glass
• Finish: Ribbed Glass (VBCR)
• Input voltage: 120V
• Wattage: 9W
• LED life span: 50,000 hours
• Country of origin: China

Before You Order

Confirm the model number WV330106VBCR and finish (Ribbed Glass) when ordering.

• Pair with an ELV wall dimmer rated for the fixture's 9W load (sold separately).
• Verify the chosen mounting location is appropriate for a damp-location rated wall fixture.
