CR3-12VDC-RGBW-5-20 Channel Ray RGBW 12v DC

Product Overview

The CR3-12VDC-RGBW-5-20 is a flexible Channel Ray LED string using SMD 5050 RGBW diodes. It combines red/green/blue color mixing with a 3000K white channel for colored and warm-white lighting on a 12V DC drive.

This SKU is sold as a single unit and is finished in white. Physical dimensions are 143.18 x 0.68 x 0.32 inches (length x width x height).

Key Features

• SMD 5050 RGBW LED array (RGB + 3000K white)
• Operates on 12V DC
• Low power: 0.96 watts per unit
• Lumen output listed at 100 lm
• Color rendering index (CRI) 70+
• White finish; flexible linear “Channel Ray” form factor

What this product does

The CR3-12VDC-RGBW-5-20 is a flexible linear LED Channel Ray designed to provide RGB color mixing plus a dedicated warm-white channel (3000K). It is intended for applications that require color-changing effects alongside a usable warm white output, such as accent cove lighting, architectural outlines, signage accents, or decorative installations where a flexible linear LED element is needed.

• RGB channels for dynamic color effects
• Dedicated 3000K white channel for warm-white illumination
• Flexible form factor for curved or continuous runs

Electrical and performance basics

This unit is specified for 12V DC operation and has a listed power draw of 0.96 W and a lumen output of 100 lm. Color rendering is specified at CRI 70+, suitable for decorative and general accent lighting where high-fidelity color is not mandatory.

• Input: 12V DC
• Power: 0.96 watts (per unit listed)
• Lumen output: 100 lumens (per unit listed)
• CRI: 70+
• Color: RGBW with 3000K white channel

Dimensions and finish

Use the listed physical dimensions to plan mounting and spacing. The unit is finished in white and provided as a flexible linear LED string suitable for integration into channels, trims, or concealed mounting locations.

• Length: 143.18 inches
• Width: 0.68 inches
• Height/thickness: 0.32 inches
• Finish: White

Technical specifications

Key technical details are summarized below. Confirm compatibility with your driver, controller, and installation method before specifying or installing.

• LED type: SMD 5050 (RGBW configuration)
• LED count: 20 pieces per string (three LEDs per cluster noted in product description)
• Part number / SKU: CR3-12VDC-RGBW-5-20
• Sold as: Each

Before You Order

Confirm the model number and quantity required before ordering. Verify compatibility with a 12V DC power supply and any RGBW controller you plan to use. This page lists the product’s manufacturer specifications as provided.

• Confirm required driver and controller support for RGBW plus 12V DC operation
• Verify physical length and mounting method fit your application
• If CRI, lumen output, or electrical needs are critical, confirm details with project documentation or manufacturer

Ordering from Lumera Electric

Check the purchasing options shown on the Lumera Electric product page for CR3-12VDC-RGBW-5-20 Channel Ray RGBW 12v DC. For project quantities or additional ordering requirements, use Request a Quote and provide the required quantity.
