Westgate 20W/30W/40W/50W 3500K/4000K/5000K/5700K LED Wall Pack LRX-20-50W-MCTP
Westgate 20W/30W/40W/50W 3500K/4000K/5000K/5700K LED Wall Pack LRX-20-50W-MCTP
Regular price
$146.74
Regular price
Sale price
$146.74
SKU:LRX-20-50W-MCTP
Quantity
Couldn't load pickup availability
The Westgate LRX-20-50W-MCTP is an LED wall pack that delivers selectable 20W / 30W / 40W / 50W output at 130 lumens per watt and 3000K/4000K/5000K/5700K for building exteriors, entrances, and perimeters for security and area lighting. It runs on 120-277V.
Key Features
- 130 LM/W efficiency keeps connected load down across the space
- Selectable 20W / 30W / 40W / 50W lets one fixture cover several output levels from stock
- Selectable 3000K/4000K/5000K/5700K sets the appearance at install rather than at order time
- 120-277V input lands on common commercial branch circuits
Technical Specifications
| Brand | Westgate |
|---|---|
| Model / SKU | LRX-20-50W-MCTP |
| Product Type | LED Wall Pack |
| Wattage | 20W / 30W / 40W / 50W (selectable) |
| Efficacy | 130 LM/W |
| Color Temperature | 3000K/4000K/5000K/5700K (selectable) |
| Voltage | 120-277V |
| Location Rating | and control requirements before ordering. Fo |
| UPC | 845060073003 |
Applications
Common applications include:
- Building entrances and perimeters
- Parking-area edges
- Security and safety lighting
- Wall-mounted HID retrofits
Compatibility and Installation Notes
Confirm the mounting height and whether a photocell or dusk-to-dawn control is required for this LED wall pack.
Lumera Electric stocks the Westgate LRX series for contractors specifying LED wall packs on commercial projects.
