Morris
Morris 91654 Heavy-Duty Lay-In Ground Pipe Clamp, 1/2" - 1" Pipe
Morris 91654 Heavy-Duty Lay-In Ground Pipe Clamp, 1/2" - 1" Pipe
Regular price
$28.28
Regular price
Sale price
$28.28
SKU:91654
Quantity
Couldn't load pickup availability
Morris's 91654 is a UL467 heavy-duty side lay-in copper ground pipe clamp for bonding up to a 4/0 conductor to 1/2" - 1" water pipe, conduit, or copper tubing. It accepts up to a 4/0 ground conductor, is cast from high-strength, high-conductivity copper, and uses stainless steel set screws.
Key Features
- For Water Pipe, Conduit, or Copper Tubing
- Accepts Up To 4/0 Ground Conductor
- Side Lay-In Configuration
- Cast of High-Strength, High-Conductivity Copper
- Stainless Steel Set Screws
- UL467 Listed for Direct Burial in Soil or Concrete
Specifications
| Brand | Morris |
|---|---|
| Catalog No. | 91654 |
| Type | Copper Ground Pipe Clamp - Heavy Duty Lay-In |
| Pipe Range | 1/2" - 1" |
| Wire Range | 4/0 - #8 AWG |
| Material | Copper |
| Set Screw | Stainless Steel |
| Listing | UL467 Direct Burial |
Applications
Used for heavy-duty direct-buried lay-in grounding of up to 4/0 conductors to 1/2" - 1" pipe in continuous ground loops and service grounding.
Installation
Lay the conductor into the side of the clamp, place it on the pipe, and tighten the stainless set screws.
