Morris 90984 Straight Solid Pin Terminal, 750 MCM Wire / 500 MCM Pin
SKU: 90984
Ready to Ship
Price:
$37.01
10% Off First Order
|
Min. Spend 200$
Description
Morris's 90984 is a straight solid pin terminal connector that terminates a 750 MCM aluminum or copper conductor into a 500 MCM solid pin. The tin-plated aluminum barrel is pre-filled with oxide inhibitor and ships with an EPDM insulating cover.
Key Features
- Straight Solid Pin Design
- All-Aluminum, Tin-Plated for Aluminum and Copper Conductors
- Barrel Pre-filled with Oxide Inhibitor
- Die Index and Crimp Marks on Barrel
- Supplied with EPDM Insulating Cover
- Rated 600 Volt
Specifications
| Brand | Morris |
|---|---|
| Catalog No. | 90984 |
| Type | Straight Solid Pin Terminal Connector |
| Wire Size | 750 MCM |
| Pin Size | 500 MCM |
| Conductor | Aluminum / Copper (Tin-Plated) |
| Color Code | Yellow |
| Voltage | 600V |
| Insulation | EPDM Cover |
| Material | Aluminum |
Applications
Used to adapt a larger conductor to a smaller equipment pin for landing aluminum or copper conductors in breakers, switches, panelboards, and lug terminals.
Installation
Strip the conductor, insert it fully into the barrel, and crimp with the marked die; slide the EPDM cover over the completed connection.
