Premium Lighting
Premium Lighting Canopy Light SUG5 240W 150lm/W 36000lm
Premium Lighting Canopy Light SUG5 240W 150lm/W 36000lm
SKU:PL-CL-SUG5-240W
Couldn't load pickup availability
Product Overview
The Premium Lighting Canopy Light SUG5 240W 150lm/W 36000lm is rated for 3 selectable wattages (150W-180W-240W) and 2 selectable color temperatures from a single fixture, set with onboard switches at install time. At full power it produces 36,000 lm (150 lm/W). Low-profile ceiling fixture for covered fueling, drive-through, and parking structures.
Key Features
- Wattage switch on the fixture lets crews set output anywhere from 150W to 240W at install, matching the photometric plan without swapping units
- Color select from 5000K to 5700K lets one fixture satisfy tenant and spec changes after rough-in
- 150 lm/W efficacy keeps operating cost low for the delivered light level
- Low-profile housing tucks under canopy decks with minimal drop
Technical Specifications
| Brand | Premium Lighting |
|---|---|
| Product Type | LED Canopy Light |
| Wattage (Max) | 240W |
| Selectable Wattage | 150W / 180W / 240W |
| Lumens (Max) | 36,000 lm |
| Efficacy | 150 lm/W |
| Selectable CCT | 5000K / 5700K |
Applications
Typical installs include:
- fuel station canopies
- drive-through lanes
- covered walkways
Compatibility and Installation Notes
Check deck thickness and pendant vs. surface mounting at the canopy before install.
Lumera Electric stocks the Premium Lighting SUG5 line for contractors standardizing on selectable led canopy light inventory.
