Morris 94536 Copper Long-Barrel Compression Splice, 500 MCM
Morris 94536 Copper Long-Barrel Compression Splice, 500 MCM
Regular price
$30.73
Regular price
Sale price
$30.73
SKU:94536
Quantity
Couldn't load pickup availability
Morris's 94536 is a copper long-barrel compression splice (butt connector) that joins two 500 MCM conductors end to end. It has a beveled entry for easy insertion, is made of high-conductivity seamless copper with electro-tin plating, has a color-coded (Brown) die index, and is UL 486AB Listed through 35kV.
Key Features
- High-Conductivity Seamless Copper
- Electro-Tin Plating Resists Corrosion
- Color-Coded Die Index and Crimp Marks Printed on Barrel
- UL 486AB Listed for Applications Through 35kV
- Inline Butt Splice
Specifications
| Brand | Morris |
|---|---|
| Catalog No. | 94536 |
| Type | Copper Long-Barrel Compression Splice |
| Conductor Size | 500 MCM |
| Barrel | Long Barrel |
| Die Color Code | Brown |
| Material | Seamless Copper, Tin-Plated |
| Rating | UL 486AB Through 35kV |
Applications
Used to splice two 500 MCM copper conductors inline in feeders, services, and equipment wiring.
Installation
Insert one conductor into each end of the barrel to the center stop and crimp both sides with the Brown-coded die.
