Morris 90980 Straight Solid Pin Terminal, 350 MCM Wire / 250 MCM Pin

Morris's 90980 is a straight solid pin terminal connector that terminates a 350 MCM aluminum or copper conductor into a 250 MCM solid pin. The tin-plated aluminum barrel is pre-filled with oxide inhibitor and ships with an EPDM insulating cover.

Key Features

• Straight Solid Pin Design
• All-Aluminum, Tin-Plated for Aluminum and Copper Conductors
• Barrel Pre-filled with Oxide Inhibitor
• Die Index and Crimp Marks on Barrel
• Supplied with EPDM Insulating Cover
• Rated 600 Volt

Specifications

Applications

Used to adapt a larger conductor to a smaller equipment pin for landing aluminum or copper conductors in breakers, switches, panelboards, and lug terminals.

Installation

Strip the conductor, insert it fully into the barrel, and crimp with the marked die; slide the EPDM cover over the completed connection.
