Morris 82851 0-10V LED Dimmer, 1-Pole/3-Way, 120/277V, 3A @ 120V

Morris's 82851 is a 0-10V LED dimmer with a 1-pole/3-way rocker control for 120/277V LED, CFL, and electronic self-ballasted lighting, rated 150W LED/CFL and 600W incandescent at 3A @ 120V; 1A @ 277V. It features adjustable high-end/low-end trim sensitivity to optimize dimming, a decorative polycarbonate housing, MOV surge suppression, conforms to California Title 24, and is cULus Listed.

Key Features

• LED Compatible
• 0-10V Dimming
• 120/277V Operation
• LED, CFL, and Electronic Self-Ballasted Applications
• Adjustable High-End/Low-End Trim Sensitivity
• Decorative PC Housing
• MOV Surge Suppression
• Conforms to California Title 24
• cULus Listed

Specifications

Applications

Used to dim 0-10V LED and fluorescent fixtures in commercial spaces on 120 or 277V with Title 24 compliance.

Installation

Wire line, load, neutral, and the 0-10V violet/gray control leads to the fixture driver, then set high/low trim.
