Morris 68050 Thin-Wall Heat Shrink Tubing, 0.078" → 0.029", 660 ft Reel, Black
Morris 68050 Thin-Wall Heat Shrink Tubing, 0.078" → 0.029", 660 ft Reel, Black
Regular price
$161.89
Regular price
Sale price
$161.89
SKU:68050
Quantity
Couldn't load pickup availability
Morris's 68050 is black flexible polyolefin thin-wall heat shrink tubing on a 660 ft reel, supplied at 0.078" and recovering to 0.029" at a 2:1 shrink ratio. It is rated 600V with continuous operation to 257°F (125°C) and is UL224 Recognized for insulating, bundling, splicing, and terminations.
Key Features
- Flexible Polyolefin Heat Shrink Tubing
- 2:1 Shrink Ratio
- 600 Volt Rated
- 257°F (125°C) Continuous Operation
- For Insulating, Wire Harness, Bundling, Splicing, and Terminations
- UL224 Recognized
- Supplied on a Continuous Reel
Specifications
| Brand | Morris |
|---|---|
| Catalog No. | 68050 |
| Type | Thin Wall Heat Shrink Tubing |
| Expanded Diameter | 0.078" |
| Recovered Diameter | 0.029" |
| Shrink Ratio | 2:1 |
| Reel Length | 660 ft |
| Color | Black |
| Voltage | 600V |
| Operating Temp | -up to 257°F (125°C) |
| Listing | UL224 Recognized |
Applications
Used for insulating, wire harnessing, bundling, splicing, and strain relief on conductors that fit the recovered diameter.
Installation
Slide the tubing over the joint and apply heat evenly until it recovers tightly to the conductor.
